$2,625 (USD)
Ships Same Day from CO, USA
Ricoh Gen5 UV Printhead MH5420 - N221414J
or
Call +1 800-787-9802
Description
Compatible Printers
Agfa Jeti Series
Mira MG2716 S/HS, Mira MG2732 S/HS, Tauro H2500, Titan HS, Titan S
CET Color Q Series
Q5-1000 / 1000h, Q5-250 / 250h, Q5-500 / 500h
Docan UV Printers
1212 UV, FR3210, FRT3116, M6, M8, M10
Durst
Alpha 190, Alpha 330
Handtop UV Series
HT1600UV HR4, HT1610UV FR4, HT2500UV HR8, HT2512UV-D FR8, HT3116UV FR8, HT3200UV HG12 / HR8
Other Systems
Akad NovaJet UV M6, Quantum Matan 5m
Key Features
- Genuine Ricoh Gen5 MH5420 OEM printhead
- Ricoh part number: N221414J
- 1280 nozzles (4 × 320) for high productivity
- Supports grayscale printing (7–35 pl drop range)
- Integrated heater and thermistor for temperature control
- Durable construction: SST, nickel alloy, epoxy adhesive
- Long lifespan: 100 billion actuations per nozzle
- Includes hose barbs (removable)
- 248mm long in total (head body + cable + connectors). The head cable is 148 mm long.
Also available:
Specifications
| Manufacturer | Ricoh |
| Model | Gen5 UV Printhead MH5420 - N221414J |
| Condition | New |
| Stock Number | ID-25000-8504 |
| Comments | The Ricoh Gen5 MH5420 printhead (Part #N221414J) is a genuine OEM industrial UV printhead designed for high-speed, high-resolution printing across UV flatbed and hybrid systems. Built with Ricoh’s advanced piezo technology, it delivers consistent droplet accuracy, grayscale capability, and long service life. This printhead includes removable hose barbs and comes fully assembled with integrated cable and connectors, ready for installation. Ships same day from Colorado, USA for fast turnaround and minimal downtime. |
